ZYLtech Precision (TRUE C7) Ball Screw 12mm 1204 w/ BF/BK10 End Support – 250mm
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| MPN | Does Not Apply |
| Model | 12mm |
| Brand | ZYLtech |
| Screw Length | 250mm |
| Type | Ball Screw |
Beware of purchasing inexpensive ballscrews as many sellers falsely claim to be offering precision-grade C7 screws. Genuine ZYLtech Anti-backlash ballscrews are true C7 grade with the following details:Precision grade C7 rolled ballscrewsTravel distance error: +/- 50 microns per 300mmMaximum Radial Runout of the Circumference of the Thread Root in Relation to the Supporting Portion Axis of the Screw Shaft : +/- 14 micronsMaximum Perpendicularity of the Supporting Portion End of the Screw Shaft to the Supporting Portion Axis: +/- 7 micronsMaximum Axial Clearance: 0.1mm (1605) or 0.05mm (1204) Specifications:This listing is for total length (including machined ends) - 250mmTotal travel approximately 180mmIncludes BF/BK10 end supportsBallnut mounting block DSG12H is also available. Please check our other listings.Please refer to the last photo for specification of machined ends.The end supports come with locking nut and retaining ring. We are in Spring, TX (Greater Houston Area). We are still OPEN and SHIPPING. 90% of the orders will be shipped within the next business day via USPS, UPS or Fedex.
