PUMP DUTY FLOAT SWITCH – 20 FT NORMALLY OPEN – WIDE ANGLE SKIVE CORD END
Specifications
| Restocking Fee | 20% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Type | Submersible, Sump |
| MPN | HF2OU20F2 |
| Brand | MDI |
These high quality float switches are designed for heavy duty loads. The float switch is as normally open or pump down (circuit is complete when the float is elevated).The float cord is intended to be attached to a vertical pipe a band clamp, cable tie or tether clamp. As an option the float can be installed with a cable weight as the pivot point.This float has a 240 VAC Piggyback Plug, where no junction boxes or complicated electrical connections are needed. Plug the switch into a standard 240 VAC outlet, and plug your pump into the piggyback plug.Operation:Normally Open (Pump Down)Cord:20' Flexible 14 Gauge 2 Conductor SJOW (UL & CSA) CPE (Chlorinated Polyethylene) JacketedRatings:15 AMP @ 240 VAC2 H.P. @ 240 VAC96 LRAOperating Angle: Wide AngleContacts close @ 45° above horizontalContacts open @ 45° below horizontalHousing:2.625" Dia x 4.625"Float Material:A.B.S. (Acrylontrile Butadiene Styrene)Operating Temperature:Up to 82ºC/180ºFPump Range:7" to 28" adjustable based upon length of cable beyond clamp / tetherFloat Switch:Mechanical (Contains no mercury) UL 508 ListedWarranty:1 Year
