POWER TEAM PA6 OTC 4020 AIR OVER HYDRAULIC FOOT PEDAL PUMP USA BUILT 10K PSI
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Model | PA6 4020 |
| Type | Hydraulic |
| MPN | PA6 4020 |
| Brand | Power Team OTC |
THE pedal pump that started it all. OEM equipment on many tools and equipment. Longest lasting, hardest working and most copied pump on the planet, buy the original buy the best. SOLD AND MARKETED AS OTC MODEL 4020 AS WELLPower TeamSPX Air Hydraulic Pump 6 CU. IN/MIN 10;000 PSI PA6FEATURES:The single-speed pumps designed to drive single-acting cylinders or tools are compact; lightweight; and portable.Operate with 40-100 psi standard shop air pressure at the pump. The air over hydraulic system uses this lower air pressure to builds hydraulic pressure to 10;000 PSI.Internal relief valves protect circuit components; air inlet filter protects motor.All metal air motor; ductile iron pump. Serviceable pump motor is not a throw away"; providing economical repair.Foot peddle pump or treadle pump allows user to control the hydraulic pressure and flow for the system.The power unit of choice for major manufacturers of auto body; frame straighteners and other equipment.SPECIFICATIONS:DIMENSIONS (IMAGE)A7-3/4"B5-7/8"C4-3/8"D9-1/2"E5"G4" x 9"GENERAL SPECIFICATIONSAir Supply Required (psi)40-120Reservoir Capacity (Cu. In.)105Reservoir Usable (Cu. In.)98Oil Port (In.)3Maximum Pressure (psi)10;000Typical Flow at Max psi6 in³/minOutlet Port Size3/8 NPTF"
