MERKLE-KORFF Precision Gearhead Motor – 12V – 85 RPM – Very High Torque Output
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| MPN | Does Not Apply |
| DC Stator/Winding Type | Permanent Magnet |
| Shaft Type | "D" Profile |
| Nominal Rated Input Voltage | 12 V |
| Shaft Diameter | 1/4 in |
| Base RPM | 85 RPM |
| Brand | MERKLE-KORFF |
MERKLE-KORFF Precision Gearhead Motor - 12V - 85 RPM - High Torque Output Gearhead motor manufactured by MERKLE-KORFF Operates on 3 - 12 VDC 85 RPM at 12V 20 RPM at 3V Speed is proportional with voltage No load current at 12V: 190mA No load current at 3V: 140mA Very high torque output, shaft extremely difficult to stop by fingers even at just 3V High quality, smooth running, heavy duty design D-Type Shaft dimensions: 5/8" L x 1/4" Diameter Motor dimensions (not including shaft): 3 3/4" L x 2" Diameter Metal gearhead has 2 threaded (M5) holes for easy mounting Comes with flexible wire leads for power / tach generator connection terminated in a 5 pin female connector (center pin blocked) and 2 Faston terminals Tach generator output: Approximately 1 V / 45 Hz per each 10 RPM of gearhead shaft (V and Hz proportional to speed). Weight: 23 oz. (650 g)
