3/8″ 24-VDC Hose Barb Electric Solenoid Valve, Plastic Body, Water etc N/C
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Refund Will Be Given As | Money Back |
| Type | Valves & Flow Controls |
| Manufacturer | EHCOTECH |
| Operation Type | NORMALLY CLOSED |
| Voltage | 24-Volt DC |
| Pressure Range | 3 to 140 psi |
| Max Temperature | 175 Deg. F |
| Brand | EHCOTECH |
| MPN | CCB-CS-24VDC |
Valves4projects — supplying high quality valves since 2004. Over 50,000 valve orders shipped. EHCOTECH CCB-CS-24VDC SOLENOID VALVE 3/8" HOSE BARBS | 24-Volt DC | Nylon Valve Body / NBR Seal | Normally Closed | 3 - 145 psi NOTE: This valve is for pressurized systems only. We have a gravity feed version of this valve in our eBay store. General Great general purpose water valve for many projects 2-way, Normally Closed (energize to open, de-energize to close), unidirectional Very Fast acting Can be mounted in any position Port / Orifice Size 3/8" hose barb inlet / outlet ports (for 3/8" inside diameter hose) Internal orifice diameter: 8 mm (about 3/8") Flow rate at 50 psi is >4GPM. Pressure and Temperature 3 to 145 psi (not for gravity feed systems) Max media temp: 175° F (80° C) For use in pressurized systems only Note: most low pressure, high volume fountain type pumps do not work with these types of solenoid valves Suitable Media Water Low viscosity fluids compantible with valve materials DO NOT use with fuels Coil / Electrical 24-Volt DC / 250mA Standard 1/4" spade connectors for electrical connection (connectors available in hardware stores, auto parts stores etc.) Wires can also also be soldered to the terminals No polarity requirements (connect positive to one termial and negative to the other) NOTE: We also carry this valve in 12VDC, 24VAC, and 120VAC voltages in our eBay store Valve Materials Valve body: Nylon Plunger and plunger guide tube: Stainless Steel (300 and 400 series) Diaphragm: NBR Diaphragm plate: Polyoxymethylene (POM) Dimensions Height: 2-7/32" Width: 2" Length: 3-1/4" Weight: 4 oz Store Policies If you are not completely satisfied, please contact us and we will make it right! 12 month warranty Copyright © Ehcotech International Inc. 2017
