1/2 HP Electronic Variable Speed Drive Motor & Control System 1270-4510 RPM New
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Speed Range | 1270 to 4510 RPM |
| MPN | Does Not Apply |
| Rated Load | 1/2 HP |
| Brand | Unbranded |
This is a 1/2 HP Permanent Magnet DC Motor with Solid State Electronic Variable Speed Control. Please read the specs completely and carefully to be certain this will work for you:1/2 HP Permanent magnet DC motor1270 to 4510 RPM no-load speed range (as measured with a digital tachometer with control powered at 122 volts)Clockwise rotation (facing end of motor shaft)(rotation can be reversed by switching the power leads inside control)TEFC (totally enclosed fan cooled)2 Mounting options on motor face as follows:(4) Screws on the motor face in a 2-5/32" (55mm) circle 90 degrees apart(2) Openings on motor mounting bracket approximately 3-3/4" (95mm) apart to accept up to 5/16" (8mm) diameter bolts 5/16" (8mm) Diameter x 1-3/4" (45mm) long output shaft with flat for set screwMotor body is 3-5/32" (80mm) diameter x 5-1/4" (154mm) long with mount bracket installedDC Motor control (solid state)Input power: 110 Volts / 3.2 amps / 1 Ph / 60 HzControls motor speed from approximately 1270 no-load RPM (slightly delayed soft start) to 4510 no-load RPM (when powered at 122 volts)Control box measures 5-1/8" long x 3-1/8" wide x 2-3/8" deepWith safety switch, variable speed control knob, built-in resetable circuit breaker, and fuseHeavy duty 6 ft grounded cordScrews included to mount control box and motorMotor produces its best torque in the top half of its speed rangeThis is a complete motor / control package ready to be mounted to your lathe, drill, mill, or any other machine requiring a 1/2 HP variable speed drive. This system is brand new but will come in generic packaging. Please study the pictures and email with any questions. Thanks for stopping by. PLEASE NOTE: We sell 2L pulleys and belts that fit this motor and help to reduce its speed. Safety Note: It is the buyer's responsibility to determine if this high speed motor is suitable for your application, to mount it securely, and to operate it in a safe manner. Failure to do so may cause injury. Shipping weight is 6-1/2 lbs.
